GMC Savana Specifications
The GMC Savana by Explorer, available in 7 and 9 passenger configurations has the space you need and the luxury you deserve. From the high quality materials and thoughtful design, to the backup cameras, rear park assist, and Bluetooth connectivity, the GMC Savana by Explorer is a paragon of luxury and comfort with the versatility you need in your busy life.
Take a look at our inventory to find the right van for your unique lifestyle, or design your van to your exact specifications. Not sure which van is right for you? Contact us and let Sheehan Vanland find the perfect fit.
Take a look at our inventory to find the right van for your unique lifestyle, or design your van to your exact specifications. Not sure which van is right for you? Contact us and let Sheehan Vanland find the perfect fit.
Available Models:
GMC Savana 2500 RWD
135" Wheelbase Model: TG23405 with YF7* Upfitter Package
GMC Savana 2500 Extended RWD
155" Wheelbase Model: TG23705 with YF7* Upfitter Package
About The Van
Exclusive Features
- Passenger 60/40 door with child safety locks
- Rear air heat with dual controls (front & rear)
- Full integrated body glass package
- Battery rundown protection
- 24 hour road side assistance
Safety Features
- StabiliTrak™
- Heavy Duty Rear Locking Differential
- Dual Frontal, Head Curtain and Side Impact Seat Air Bags
- 4 wheel anti lock disc brakes with front disc brake wear sensor
- Full length boxed frame chassis
- Daytime running lights
- Keyless entry with panic button and remote start
- Dual composite Halogen headlamps
- Full size spare tire
- 4G Onstar™ (limited availability)
- Bluetooth
- MyLink Navigation (limited availability)
- Tire Pressure Monitoring SYS
- Rear Park Assist
- Rearview Camera
Power Group Features
- 6 way power driver and pedestals
- AM/FM/XM/CD/USB/AUX/Bluetooth Front Radio with 6 Speaker Sound System
- Power windows
- Power mirrors with heat
- Power door locks with lock out protection
- Tilt wheel
- Cruise control
Powertrain
- 6.0 liter V-8 Vortec Gen III 323 H.P.
- 3.42 Rear axle ratio
- New 6 speed automatic overdrive transmission with Tow / Haul mode
- HD 145 amp alternator 8600 GVWR
- 31 Gal fuel tank
- Fuel Economy: 14 City / 18 Highway
- Flex fuel capability
- Heavy duty trailering equipment
- 5 Year/ 60,000 mile Powertrain Limited Warranty
- 2 Maintenance Visits, Oil and Filter, 4 Wheel tire rotation
Dimensions
| 7 Passenger | 9 Passenger | |
|---|---|---|
| Wheelbase |
135.0"
|
155.0"
|
| Overall Length |
224.1"
|
244.1"
|
| Overall Height (Low Top) |
82.0"
|
82.0"
|
| Overall Height (Sport Roof) |
94.0"
|
94.0"
|
| Body Width |
79.4"
|
79.4"
|
| Swing-Out Side Doors - Height |
47.9"
|
47.9"
|
| Swing-Out Side Doors - Width (With Both Doors Open) |
44.1"
|
44.1"
|
| Rear Doors - Height |
49.4"
|
49.4"
|
| Rear Doors - Width |
57.0"
|
57.0"
|
| Headroom (Low Top) |
51.0"
|
51.0"
|
| Headroom (Sport Roof) |
62.0"
|
62.0"
|
| Seating Capacity |
7
|
9
|
| Legroom - 1st Row Seating |
25.0"
|
25.0"
|
| Legroom - 2nd Row Seating |
20.0"
|
17.0"
|
| Legroom - 3rd Row Seating |
20.0"
|
17.0"
|
| Legroom - 4th Row Seating |
N/A
|
17.0"
|
| Cargo Room Behind Sofa - Back Position |
34 cu. ft/24" of Floor Space
|
34 cu. ft/24" of Floor Space
|
| Cargo Room Behind Sofa - Forward Position |
41 cu.ft./31" of Floor Space
|
41 cu.ft./31" of Floor Space
|
Capacities
| 7 Passenger | 9 Passenger | |
|---|---|---|
| Axle Ratio | 3.42 | 3.42 |
| Max Trailer/Towing Capacity (lbs)** | 10,000 | 10,000 |
| Curb Weight - (lbs) (Before Conversion) | 5,338 | 5,547 |
| Gross Vehicle Weight Rating (GVWR) (lbs) | 8,600 | 8,600 |
| Payload (lbs) | 3,262 | 3,053 |
| Horsepower | 342 | 342 |
| Torque (lb-ft) | 373 | 373 |
Conversion Features
Standard Features
- Molded Automotive Style Walls & Headliners
- R-11 Factor Fiberglass Insulation
- High Gloss Simulated Wood Appointments Includes — All Door Pods
- Window Ledges With Enhanced Automotive Décor & Dual Drink Holders
- 4 Hi-Back Low-Profile Integrated Headrest Seating With Automotive Style Seat Skirting, High Density Molded Foam
- Quick Release Middle Captain Chairs
- 3 Way Rear Sofa With Arm & Headrests With Expandable Storage On Back
- Heavy Duty Fade & Stain Resistant Fabrics
- Full One Piece Carpet With Closed-Cell Foam Floor For Insulation & Noise Resistance
- Carpet Floor Mats For All Seats
- 6 Sets Of 2 Position Reading Lamps
- Aluminum Step Plates With No Skid Strips In Stepwells
- Color Coded Wiring Harness With Automotive Plugs
- Easy Access Fuse Panel
- Full Width Automotive Overhead Console With Wood Accents
- Backlit Control Panel For All Interior Lighting
- Indirect Lighting Package
- Aux 12-Volt Power Outlets
- Cloth Shades On All Windows
- Leather Double Stitched Window Valances
- Automotive Style Center Ice Chest With Storage & Insulated Cooler
- Factory AM/FM Radio & CD With Acoustical 6 Speaker Sound Systems
- 2 Garment Hangers
- Assist Handles Above Cargo Doors
- Automotive Style Leather Door Kits With Built-In Drink Caddy's On Side Doors
- Automotive Style Double Stitched Leather Wings With Storage Compartments (Sport Roof Only)
- Rear Storage Compartment For The Tire Jack & Lug Wrench
- 4 Courtesy Entry Lights
Exterior Standard Features
- Automotive Low-Profile Roof Rack
- Deluxe Dye Cut Exterior Graphics Or Matching Body Side Molding
- Complete Full Running Board Package With Wheel Flares
Chassis Standard Features
- Remote Vehicle Starter Systems
- Stabilitrak
- Driver Information Center
- Fuel Range
- Average Speed
- Oil Life
- Tire Pressure Sensors
- Fuel Used
- Ice Warning
- Engine Hours
- Outside Temperature
- Average Economy
- Digital Compass Display
- Tachometer
- Maintenance Reminders
- Steering Wheel Controls For Radio & Information Center
- Automatic Lighting
- New Generation 5 Engine
- Onstar
- Blue Tooth
- XM Satellite Radio
- Backup Sensors
- In Motion Rear View Camera
- GM Navigation (Check Availability)
*Only available through approved GM converter.
**Please Refer to Chassis Owner's Manual For Towing and Trailer Capacities.
All pricing & equipment subject to change without notice, see your dealer for details.
